860-960MHz UHF Washable Rfid Laundry Tag

China Shenzhen ZDCARD Technology Co., Ltd. certification
China Shenzhen ZDCARD Technology Co., Ltd. certification
I'm Online Chat Now

860-960MHz UHF Washable Rfid Laundry Tag

860-960MHz UHF Washable Rfid Laundry Tag
860-960MHz UHF Washable Rfid Laundry Tag 860-960MHz UHF Washable Rfid Laundry Tag 860-960MHz UHF Washable Rfid Laundry Tag

Large Image :  860-960MHz UHF Washable Rfid Laundry Tag

Product Details:
Place of Origin: Shenzhen, China
Brand Name: ZDCARD
Certification: ISO 9001, 14001, OHSAS18001
Model Number: ATAG-05
Payment & Shipping Terms:
Minimum Order Quantity: 500pcs
Price: Negotiable
Packaging Details: 100pcs/bag,5000pcs/ctn
Delivery Time: 6-12 work days
Payment Terms: T/T, Paypal, Western Union
Supply Ability: 100,000,000 pcs per month

860-960MHz UHF Washable Rfid Laundry Tag

Material: Textile Size: 38*20mm
Chip: NXP UCODE8 Reading Distance: 5-7m
OperatingFrequency: UHF(860-960 MHz) Protocol: EPC Global Class 1 Gen2/ ISO18000-6C
Washing Cycles: 230 Cycles Pressure: 80-120bar
Feature: Washable, High Temperature Resist, Recyclable Color: White
High Light:

Washable Rfid Laundry Tag


UHF Rfid Laundry Tag


860-960MHz Rfid Laundry Tag

860-960MHz UHF Washable RFID Uniform Laundry Tags Flat Linen Textile Tags 38*20mm

We have created the most complete RFID product portfolio to identify and track every specific kind of textile: flat linen (bed sheets, tablecloths, napkins, pillows…), work wear (uniforms, smocks..), private wear, mats and mops.

Invisible RFID tags sewn into bed linen and towels enable hotel management to track guest linen/towels and to control the lifecycle of employees’ uniforms. Tracking linen helps to prevent lost or stolen items, reduces costs, increases efficiency and streamlines inventory.
The systematic tracking of items eases communication between the hotel and the laundry, leaving more time for the hotel to focus on its guests.


The advaNFCes of this tag:

1. Double-sided pressing process, the outer layer of the chip has a large black rubber area to better protect the chip.

2. The chip is NXP's latest UHF chip UCODE8, which has high sensitivity, best group read performance (very important in washing), and the chip can be automatic frequency-modulated, according to the frequency of the reader, so it has stable and reliable RF performance.

3. Applied to industrial washing, capable of 80-120bar pressure.

4. Our test result is 270 times wash cycles, so 200 times is completely no problem.





DIMENSION(+/-5%) SEWING:20mm x 87mm SACK:18mm x 87mm 15mmx87mm  Mini :20mm x 60mm
THICKNESS(+/-5%) 2.3mm (on-chip location only ) ; 0.8mm(rest of tag)
Reading Range 6m by ARFID’s Handset in bath towel test , 8m by Moto RFID PDA
Group Read 1000pcs
Storage Conditions 40℃/77℉, 50%RH


MAXIMUM TEMPERATURE EXPOSURE 220℃ (392℉) |30Seconds | 2.5 bars(36,28PSI)
WASHING 100℃ (194℉) | 60minutes 120Bar
PRE-DRYING IN TUMBLER 160℃ (320℉) | 30minutes
TUNNEL FINISHER 185℃ (365℉) | 30minutes
STERILIZATION PROCESS 134℃ (273℉) | 20minutes
WARRANTY New Encapsulation: 250cycles or 3years


EPC Gen2, ISO 18000-6C, UCODE 8/8m NXP
Up to 128-bit of EPC memory
96-bit EPC
96-bit Tag IDentifier (TID) factory locked
48-bit unique serial number factory-encoded into TID
32-bit User Memory(UCODE 7m Only ),
32-bit kill password to permanently disable the tag ;32-bit access password; Product Status Flag bit: enables the UHF RFID tag to be used as EAS
Wide operating temperature range: -40℃ up to +85℃
